SPECIFICATIONS

Ambient Humidity: 5 to 95%

Ambient Temperature Range: -25 to 55°C

Brand Name: NONE

Charger Capacity: 20/30/40kW

Condition: New

Display & Screen Size: 7 Inches Screen

High-concerned chemical: None

Input Voltage: AC380V±15%/ AC480V±15%

InputFrequency: 45-65Hz

Interface Standard: CCS1

Model Number: ANSI-DCB020A/ ANSI-DCL020A

Origin: Mainland China

Output Current: DC

Output Power: 20kW

Output voltage: AC380V±15%/ AC480V±15%

Purpose: Commercial

Type of Each Output: DC200-1000V

User Authentication: QR Code/Password(Optional)

protection grade: IP54

rated power: 20KW



PLEASE NOTE:
1.This is a custom made item.
2.The price onyfor reference,the specific cost based on your equirements and the destination port, please contact us for more product detalsand quotations.
3.If you are interested, please contact me using the following methods.

4.Due to differences in products and sizes across countries, all product prices on our website do not include shipping costs. Final shipping costs will be calculated based on actual costs; please confirm with us before placing your order.

WA/Telephone:+8613733839562
Email address:Lechi06@163.com

Parameters	Requirements
EV Charger Type	DC
Charger Capacity	20/30/40kW
AC Supply System	three-phase five-wire
Nominal Input Voltage	AC380V±15%/ AC480V±15%
InputFrequency	45-65Hz
Ambient Temperature Range	-25 to 55°C
Ambient Humidity	5 to 95%
Storage Temperature	-40 to 70°C
IP Ratings	IP 54
Cooling	Air-cooled
Number of Outputs	1
Type of Each Output	DC200-1000V
Single Output Max. Current	66/100/132 Amp
Display & Screen Size	7 Inches Screen
User Authentication	QR Code/Password(Optional)
Metering Information	Consumption Units
Communication between EVSE and Central Server	OCPP1.6/OCPP2.0.1 (Optional)
Interface between Charger and CMS	Ethernet/3G/4G/WIFI (Optional)
Output interface	CCS1/NACS/CCS2/CHAdeMO/GBT（Optional）
Safety Parameters	Over Current, Under Voltage, Under Current, Over Voltage, Residual Current, Surge Protection, Leakage Protection, Short Circuit, Over Temperature, etc.
